Запчасти Komatsu PC400LC-5 ТОПЛИВОПРОВОД. ТОПЛИВН. СИСТЕМА

2

6150-21-6120

BRACKET

3

04020-01024

PIN, DOWEL

4

01010-81080

BOLT

5

01010-81070

BOLT

6

01643-31032

WASHER

7

01010-30875

BOLT

8

6110-71-5810

WASHER

|$8

6150-71-3100

CASE ASSEMBLY

9

6150-71-3111

CASE

10

6150-71-3120

SHAFT

11

06030-06307

BEARING, BALL

12

04065-08025

RING, SNAP

13

6138-71-3230

GEAR

14

06000-06005

BEARING, BALL

15

6150-71-3150

SEAL, OIL

|$16

6150-81-5200

DRIVE ASSEMBLY, TACHOMETER

16

6150-71-1610

SHAFT

17

6110-73-3220

GEAR

18

6150-71-1620

BUSHING

19

6150-71-1910

SEAL

20

6162-73-1960

WASHER, FELT

21

6162-73-1970

SPACER

22

6162-73-1920

HOUSING

23

6162-73-1930

GASKET

24

6110-73-3511

SCREW

25

01641-20608

WASHER

26

6136-81-5291

CAP

27

6130-82-5270

GASKET

28

04010-00516

KEY

29

07000-62125

O-RING

30

6150-71-3210

GEAR

31

04010-00519

KEY

32

01583-12414

NUT

33

01643-32460

WASHER

34

01010-81025

BOLT

35

6150-71-5111

TUBE, FUEL INJECTION - NO. 1

36

6150-71-5121

TUBE, FUEL INJECTION - NO. 2

37

6150-71-5131

TUBE, FUEL INJECTION - NO. 3

38

6150-71-5141

TUBE, FUEL INJECTION - NO. 4

39

6150-71-5151

TUBE, FUEL INJECTION - NO. 5

40

6150-71-5161

TUBE, FUEL INJECTION - NO. 6

41

6151-73-5510

CLAMP

42

6151-73-5520

CLAMP

43

01010-81055

BOLT

44

6134-71-5701

CLIP (WITH THREAD)

45

6134-71-5711

CLIP

46

01010-80630

BOLT

47

01602-20619

WASHER, LOCK

48

6151-71-5660

TUBE

49

6127-71-5710

BOLT, CONNECTOR

50

07005-01412

GASKET

51

6150-71-5710

TUBE

52

07206-11014

BOLT, CONNECTOR

53

07005-01412

GASKET

54

6151-71-3810

COVER, SAFETY

55

01010-81020

BOLT
