Запчасти Komatsu PC400LC-5 LUBE МАСЛООХЛАДИТЕЛЬ СИСТЕМА СМАЗКИ МАСЛ. СИСТЕМА

1

6150-61-2123

COVER, OIL COOLER

2

6151-61-2111

CORE, OIL COOLER

3

6150-61-2510

O-RING

4

6150-61-2560

GASKET

5

01582-01008

NUT

6

01602-21030

WASHER, LOCK

7

01640-21016

WASHER

8

6150-61-2530

PLUG

9

6150-61-2550

O-RING

10

6150-61-2540

SEAL

|$10

6151-63-2140

CASE

11

6212-65-2610

THERMOSTAT, ENGINE OIL COOLER

|$12

6151-63-2620

VALVE

12

6150-61-2141

CASE

|$14

6151-63-2640

SPRING

13

6150-61-2151

PLATE

|$16

6151-63-2160

SEAT

14

6150-61-2131

COVER

15

07000-63042

O-RING

16

01435-00825

BOLT

17

6150-61-2812

GASKET, OIL COOLER

18

01010-81025

BOLT

19

01010-81065

BOLT

20

01010-81080

BOLT

21

01640-21016

WASHER

24

203-977-4130

VALVE, DRAIN

25

07286-01425

HOSE, DRAIN

26

07285-00180

CLIP

27

6101-61-6620

CLAMP

10

6150-61-2540

SEAL

11

6212-65-2610

THERMOSTAT, ENGINE OIL COOLER

12

6150-61-2141

CASE

13

6150-61-2151

PLATE
