Запчасти Komatsu PC400LC-5 ПОРШЕНЬ И ШАТУН БЛОК ЦИЛИНДРОВ

1

6151-31-2511

PISTON, ENGINE

2

6151-31-2410

PIN, PISTON

3

04065-04818

RING, SNAP

|$3

6150-31-2033

SET, PISTON RING

4

NSS

RING, TOP

5

NSS

RING, MIDDLE

6

NSS

RING, OIL

|$7

6151-31-3101

ROD, CONNECTING

7

NSS

ROD, CONNECTING

8

NSS

CAP, CONNECTING ROD

9

6150-31-3130

BUSHING

10

6150-31-3310

BOLT

11

02400-10413

PIN, DOWEL

|$13

6151-31-3040

BEARING, CONNECTING ROD - (STD)

12

NSS

BEARING, LOWER

13

NSS

BEARING, UPPER

|$16

6151-39-3040

BEARING, CONNECTING ROD - (0.25 MM UNDER)

12

NSS

BEARING, LOWER

13

NSS

BEARING, UPPER

|$19

6151-38-3040

BEARING, CONNECTING ROD - (0.50 MM UNDER)

12

NSS

BEARING, LOWER

13

NSS

BEARING, UPPER

|$22

6151-37-3040

BEARING, CONNECTING ROD - (0.75 MM UNDER)

12

NSS

BEARING, LOWER

13

NSS

BEARING, UPPER

|$25

6151-36-3040

BEARING, CONNECTING ROD - (1.00 MM UNDER)

12

NSS

BEARING, LOWER

13

NSS

BEARING, UPPER
