Запчасти Komatsu PC400LC-5 КОЛЕНВАЛ БЛОК ЦИЛИНДРОВ

|$0

6151-31-1010

CRANKSHAFT ASSEMBLY

1

NSS

CRANKSHAFT

2

6150-31-1121

GEAR, CRANKSHAFT

3

6150-31-1130

KEY

4

6150-31-1550

PULLEY, CRANK

|$5

6150-31-1560

PULLEY, CRANK - HARDENED

5

01051-51430

BOLT

6

6130-32-1361

WASHER

7

01051-51635

BOLT

8

6150-31-1810

WASHER

9

6151-31-8100

DAMPER, VIBRATION

10

04020-01228

PIN, DOWEL

11

01010-81225

BOLT

|$13

6150-21-8010

BEARING, MAIN (STD)

12

NSS

BEARING, UPPER

13

NSS

BEARING, LOWER

14

6150-21-8050

BEARING, THRUST

|$17

6150-29-8010

BEARING, MAIN (0.25 MM UNDER)

12

NSS

BEARING, UPPER

13

NSS

BEARING, LOWER

14

6150-29-8050

BEARING, THRUST (0.25 MM UNDER)

|$21

6150-28-8010

BEARING, MAIN (0.50 MM UNDER)

12

NSS

BEARING, UPPER

13

NSS

BEARING, LOWER

14

6150-28-8050

BEARING, THRUST (0.50 MM UNDER)

|$25

6150-27-8010

BEARING, MAIN (0.75 MM UNDER)

12

NSS

BEARING, UPPER

13

NSS

BEARING, LOWER

14

6150-27-8050

BEARING, THRUST (0.75 MM UNDER)

|$29

6150-26-8010

BEARING, MAIN (1.00 MM UNDER)

12

NSS

BEARING, UPPER

13

NSS

BEARING, LOWER

14

6150-26-8050

BEARING, THRUST (1.00 MM UNDER)
