Запчасти Komatsu PC400LC-5 БЛОК ЦИЛИНДРОВ БЛОК ЦИЛИНДРОВ

|$0

6151-25-1301

BLOCK ASSEMBLY, CYLINDER

1

NSS

BLOCK, CYLINDER

2

6150-29-1490

BUSHING, CAMSHAFT

3

6150-29-1210

CAP, MAIN BEARING - NO. 1, 2, 3, 4, 5, 6

4

6150-21-1250

CAP, MAIN BEARING - NO. 7

5

6150-21-1710

BOLT

6

01643-31645

WASHER

7

07043-00108

PLUG

8

07040-12414

PLUG

9

07002-22434

O-RING

10

07040-13016

PLUG

11

07002-23034

O-RING

12

07043-50617

PLUG

13

07046-43016

PLUG

14

07046-44016

PLUG

15

07046-22516

PLUG

16

07046-21210

PLUG

17

07043-50211

PLUG

18

04020-00820

PIN, DOWEL

19

6150-21-1170

TUBE

20

6150-41-2430

PIN

21

6110-53-5910

PLUG

22

07005-01412

GASKET

23

04020-00514

PIN, DOWEL

24

04025-00408

PIN, SPRING

25

04025-00512

PIN, SPRING

26

6150-41-2430

PIN

27

04020-01024

PIN, DOWEL

28

6150-21-4770

PIN, DOWEL

29

01050-31012

BOLT

30

07005-01012

GASKET

31

6150-21-5910

BUSHING

32

07046-22010

PLUG

33

6151-21-1840

NOZZLE, PISTON COOLING

34

6151-21-1851

PIN

35

6150-81-9230

BOLT

36

6151-21-2220

LINER, CYLINDER

37

6150-21-2230

O-RING, LOWER

38

6150-21-2240

O-RING, UPPER

39

6150-21-2250

SEAL, CREVICE

40

6150-21-1180

PLUG

41

6150-21-1190

O-RING

42

07046-42816

PLUG

43

08073-10505

SWITCH, OIL PRESSURE
