Запчасти Komatsu PC400LC-5 ВОЗДУХООЧИСТИТЕЛЬ КРЕПЛЕНИЕ И ПАТРУБКИ - заводской номер THRU 887 ГОЛОВКА ЦИЛИНДРОВ

|$0

6151-81-7750

CLEANER, AIR

1

6151-81-7850

BODY

|$2

600-181-1600

ELEMENT ASSEMBLY, AIR CLEANER

2

NSS

ELEMENT, INNER - AIR CLEANER

3

600-181-4370

NUT

4

600-181-7511

WASHER

|$6

600-181-1660

ELEMENT ASSEMBLY, OUTER

5

NSS

ELEMENT, OUTER - AIR CLEANER

6

561-02-62550

NUT

7

600-181-4440

GASKET

|$10

600-181-1980

COVER ASSEMBLY

8

600-181-1690

COVER

9

600-181-1770

GASKET

10

561-02-62370

NUT ASSEMBLY

11

561-02-12380

CLIP

12

600-181-1370

VALVE

13

6151-13-4271

DUCT

14

6151-13-4280

INSULATOR

15

07281-00909

CLAMP

16

6151-13-4290

INSULATOR

17

07281-01469

CLAMP

18

6151-13-5640

PLATE

19

01010-81045

BOLT

20

01580-01008

NUT

21

01640-21016

WASHER

22

6151-13-4560

BRACKET

23

01010-81660

BOLT

24

01010-81025

BOLT

25

6151-11-4840

BAND ASSEMBLY

|$29

6691-21-6550

PIN

|$30

6691-21-6560

PIN (WITH THREAD)

26

6643-11-4641

BOLT

27

08670-01001

INDICATOR, AIR CLEANER SERVICE

28

09639-00305

PLATE, INSTRUCTION

29

09638-50305

PLATE, CAUTION

30

6151-13-5631

BRACKET - MUFFLER MOUNTING
