Запчасти Komatsu PC400LC-5 ТУРБОНАГНЕТАТЕЛЬ ТРУБЫ ГОЛОВКА ЦИЛИНДРОВ

|$0

6151-11-4910

MANIFOLD ASSEMBLY, INTAKE

1

6151-11-4110

MANIFOLD, INTAKE

2

07042-00415

PLUG

3

07042-00108

PLUG

4

6150-13-4810

GASKET, INTAKE MANIFOLD

5

01010-81030

BOLT

6

01010-81045

BOLT

7

01010-81060

BOLT

8

01011-31045

BOLT

9

01011-31010

BOLT

10

01640-21016

WASHER

11

6631-11-6390

SPACER

12

6206-81-9870

SPACER

13

6151-11-4362

CONNECTOR

13

6151-13-4361

CONNECTOR

14

07042-00108

PLUG

15

600-815-3811

HEATER, RIBBON

16

6150-11-4821

GASKET

17

01010-81055

BOLT

18

01011-81075

BOLT

19

01640-21016

WASHER

20

6151-11-4410

HOSE

20

6151-13-4410

HOSE

21

07281-00909

CLAMP

21

07281-00809

CLAMP

22

6151-81-4510

BRACKET

23

01010-81020

BOLT (WITHOUT WATER SEPARATOR)

|$27

01010-81030

BOLT (WITH WATER SEPARATOR)

24

01010-81035

BOLT (WITH WATER SEPARATOR)

25

600-815-2170

SWITCH, HEATER

26

01010-80610

BOLT

27

01640-20610

WASHER

28

6151-81-4590

PLATE

29

6151-81-4490

WIRE, (160 MM)

30

08038-00519

CAP

31

600-050-2420

CLIP
