Запчасти Komatsu PC400LC-5 ГОЛОВКА ЦИЛИНДРОВ заводской номер 888 И UP ГОЛОВКА ЦИЛИНДРОВ

|$0

6151-11-1100

HEAD, CYLINDER - LESS VALVES

1

NSS

HEAD, CYLINDER

2

6136-11-1130

SLEEVE

3

6150-11-1331

INSERT, INTAKE VALVE (STD)

|$4

6150-19-1331

INSERT, INTAKE VALVE (0.25 MM)

|$5

6150-18-1331

INSERT, INTAKE VALVE (0.50 MM)

|$6

6150-17-1331

INSERT, INTAKE VALVE (0.75 MM)

|$7

6150-16-1331

INSERT, INTAKE VALVE (1.00 MM)

4

6150-11-1320

INSERT, EXHAUST VALVE (STD)

|$9

6150-19-1320

INSERT, EXHAUST VALVE (0.25 MM)

|$10

6150-18-1320

INSERT, EXHAUST VALVE (0.50 MM)

|$11

6150-17-1320

INSERT, EXHAUST VALVE (0.75 MM)

|$12

6150-16-1320

INSERT, EXHAUST VALVE (1.00 MM)

5

6150-12-1341

GUIDE, INTAKE VALVE

6

6150-12-1351

GUIDE, EXHAUST VALVE

7

6150-11-1140

GUIDE

8

6162-13-1150

PLUG

9

04020-00820

PIN, DOWEL

10

6150-41-4111

VALVE, INTAKE

11

6150-41-4210

VALVE, EXHAUST

12

6150-41-4540

ROTATOR, INTAKE VALVE

13

6140-41-4540

SEAL, EXHAUST VALVE

14

6150-41-4430

SEAT, LOWER

15

6150-41-4510

SEAT, UPPER

16

6136-42-4520

COLLET

17

6150-41-4420

SPRING, INTAKE

18

6150-41-4411

SPRING, EXHAUST

19

6150-41-5611

CROSSHEAD

20

6150-41-5620

SCREW, ADJUSTING

21

6150-41-5630

NUT

22

6150-17-1813

GASKET, CYLINDER HEAD

23

6150-11-1920

GROMMET, OIL

24

6150-11-1930

GROMMET, OIL

25

6150-11-1940

GROMMET, WATER

26

6150-11-1610

BOLT

27

6150-81-9160

BOLT
