Запчасти Komatsu PC400LC-5 КОНЕЧНАЯ ПЕРЕДАЧА И ЗВЕЗДОЧКА ХОД И НИЖН.CARRIAGE

|$0

208-27-00102

FINAL DRIVE ASSEMBLY

1

07002-02434

O-RING

2

07044-12412

PLUG

3

208-27-52310

BOLT

N/I

17M-27-00101

SEAL ASSEMBLY, FLOATING

N/I

17M-27-00110

RING ASSEMBLY, SEAL

5

17M-27-12250

RING, SEAL

N/I

421-33-00030

O-RING ASSEMBLY

6

502-33-91120

O-RING

7

208-27-51211

COVER

8

208-27-51240

BEARING, BALL

9

208-27-52160

HUB

10

208-27-52350

O-RING

11

208-27-31221

SPROCKET

12

208-27-00110

SPACER KIT

|$16

208-27-51280

SPACER 0.1279 IN (3.25 mm)

|$17

208-27-51290

SPACER 0.1299 IN (3.30 mm)

|$18

208-27-51310

SPACER 0.1318 IN (3.35 mm)

|$19

208-27-51320

SPACER 0.1338 IN (3.40 mm)

|$20

208-27-51330

SPACER 0.1358 IN (3.45 mm)

|$21

208-27-51340

SPACER 0.1377 IN (3.50 mm)

|$22

208-27-51350

SPACER 0.1397 IN (3.55 mm)

13

208-27-52170

RETAINER

14

208-27-52181

CARRIER

15

208-27-52230

BEARING, ROLLER

16

208-27-52140

GEAR

17

208-27-52271

HOLDER

18

208-27-52250

PIN

19

01011-52210

BOLT

20

207-27-52270

SPACER

21

208-27-52130

GEAR

22

208-27-52110

SHAFT

23

208-27-52190

CARRIER

24

208-27-52120

GEAR

25

208-27-52240

PIN

26

01010-51265

BOLT

27

208-27-52220

BEARING, ROLLER

28

208-27-52260

HOLDER

29

20Y-27-11250

SPACER

30

208-27-52150

GEAR

31

04260-01905

BALL

32

208-27-51211

COVER

33

07049-01215

PLUG

34

01010-51240

BOLT

35

01643-31232

WASHER

36

207-27-51310

BOLT

37

208-27-52341

BOLT

38

01643-31845

WASHER

39

208-27-52281

GEAR

N/I

04020-01024

DOWEL, PIN

40

01011-52000

BOLT

41

01643-32060

WASHER
