Запчасти Komatsu PC400LC-5 РЕГУЛЯТОР SPRING PACK ТОПЛИВН. СИСТЕМА

1

1241 687 H1

COVER, SPRING PACK

2

1240 060 H1

GASKET, SPRING PACK

|$2

1294 477 H91

PACK, SPRING

3

1239 706 H1

GUIDE, IDLE

4

1239 628 H1

SPRING, COMPRESSION

5

1240 063 H1

SCREW, KNURLED

6

1239 406 H1

SPRING, COMPRESSION

7

1238 053 H1

RING, RETAINING

8

1239 369 H1

BOLT, W/WASHER

9

1239 370 H1

BOLT, W/WASHER

10

1240 085 H1

PLUNGER, THROTTLE LEVER

11

1241 688 H91

PLUG, PIPE

12

1295 217 H1

PLUNGER, IDLE SPRING

13

1239 067 H1

SEAL, WIRE

14

1238 629 H1

SPACER, MOUNTING

15

1240 062 H1

WASHER, PLAIN

16

1240 064 H1

SHIM - 0.020 IN

|$17

1240 065 H1

SHIM - 0.010 IN

|$18

1240 066 H1

SHIM - 0.005 IN

|$19

1238 449 H1

SHIM - 0.007 IN

|$20

1238 511 H1

SHIM - 0.007 IN

17

1238 304 H1

SPRING, COMPRESSION

|$22

1239 452 H91

COVER, SPRING PACK

18

1239 341 H91

COVER, SPRING PACK

19

1239 230 H1

BUSHING

20

1240 048 H1

O-RING

21

1238 182 H1

SCREW, ADJUSTING

22

1240 080 H1

SCREW, SET

23

1239 231 H1

SHAFT, THROTTLE

24

1240 084 H1

STOP, THROTTLE SHAFT

25

1239 233 H1

SEAL, DUST

26

1238 184 H1

NUT, FUEL PUMP ADJUSTING

27

1250 262 H1

NUT, HEX

28

1238 192 H1

WASHER, PLAIN

|$34

1237 963 H91

PACK, IDLING

29

1240 082 H1

PLUNGER, GOVERNOR

30

1240 083 H1

RING, SNAP

31

1240 075 H1

GUIDE, SPRING

32

1238 357 H1

SPRING, COMPRESSION

33

1240 077 H1

SHIM - 0.020 IN

|$40

1240 078 H1

SHIM - 0.010 IN

|$41

1240 079 H1

SHIM - 0.005 IN

34

1295 218 H1

SPRING, GOVERNOR
