Запчасти Komatsu PC400LC-5 КОЛЕНВАЛ БЛОК ЦИЛИНДРОВ

1

1294 026 H1

CRANKSHAFT, ENGINE

2

1246 143 H1

KEY, PLAIN WOODRUFF

3

1294 025 H1

GEAR, CRANKSHAFT

4

1240 556 H1

SLEEVE, WEAR

5

1296 127 H1

SLEEVE, WEAR

|$5

1246 138 H91

SET, MAIN BEARING - STD

6

1246 139 H1

BEARING, MAIN - UPPER

7

1246 140 H1

BEARING, MAIN - LOWER

8

1246 141 H1

BEARING, THRUST - NO. 4 MAIN

|$9

1240 512 H91

SET, MAIN BEARING - .010 IN O/S

6

1240 434 H1

BEARING, MAIN - UPPER

7

1240 438 H1

BEARING, MAIN - LOWER

8

1246 141 H1

BEARING, THRUST - NO. 4 MAIN

|$13

1240 513 H91

SET, MAIN BEARING - .020 IN O/S

6

1240 435 H1

BEARING, MAIN - UPPER

7

1240 439 H1

BEARING, MAIN - LOWER

8

1246 141 H1

BEARING, THRUST - NO. 4 MAIN

|$17

1240 514 H91

SET, MAIN BEARING - .030 IN O/S

6

1240 436 H1

BEARING, MAIN - UPPER

7

1240 440 H1

BEARING, MAIN - LOWER

8

1246 141 H1

BEARING, THRUST - NO. 4 MAIN

|$21

1240 515 H91

SET, MAIN BEARING - .030 IN O/S

6

1240 437 H1

BEARING, MAIN - UPPER

7

1240 441 H1

BEARING, MAIN - LOWER

8

1246 141 H1

BEARING, THRUST - NO. 4 MAIN

8

1240 479 H1

BEARING, THRUST - .010 IN O/S
