Запчасти Komatsu PC400LC-5 ПРОМЕЖУТОЧНАЯ ШЕСТЕРНЯS БЛОК ЦИЛИНДРОВ

|$1

1246 145 H91

GEAR ASSEMBLY, IDLER

1

NSS

GEAR, IDLER - CAMSHAFT

2

1246 146 H1

BUSHING

3

1246 147 H1

SHAFT, IDLER

4

1246 148 H1

RETAINER, GEAR

5

1246 151 H2

BEARING, THRUST

6

1246 150 H1

PLATE, THRUST BEARING WEAR

7

1246 149 H1

BOLT

|$11

1246 152 H91

GEAR ASSEMBLY, IDLER

8

NSS

GEAR, IDLER - WATER PUMP

9

1246 153 H1

BUSHING

10

1246 148 H1

RETAINER, GEAR

11

1246 151 H2

BEARING, THRUST

12

1246 149 H1

BOLT

13

1246 154 H1

SHAFT, IDLER

14

1294 037 H1

RETAINER, GEAR

15

1294 044 H1

SCREW, TWELVE POINT CAP

16

1294 043 H1

SHAFT, IDLER

17

1246 116 H1

DOWEL, RING

18

1294 035 H2

SEAL, RECTANGULAR RING

19

1294 036 H1

SPACER, MOUNTING
