Запчасти Komatsu PC400LC-5 ТУРБОНАГНЕТАТЕЛЬ ГОЛОВКА ЦИЛИНДРОВ

|$0

1295 249 H91

TURBOCHARGER

1

1294 186 H1

HOUSING, COMPRESSOR

2

NSS

DATAPLATE

3

1246 461 H1

PLATE, CLAMPING

4

1295 250 H1

HOUSING, TURBINE

5

1240 507 H1

BOLT

6

1246 471 H1

SCREW, DRIVE

7

1246 484 H1

RING, RETAINING

8

1246 485 H1

PLATE, OIL SEAL

9

1246 480 H1

SEAL, SPLIT RING

10

1294 188 H1

HOUSING, TURBINE BEARING

11

1246 467 H1

BAFFLE, OIL

12

1246 468 H1

BEARING, TURBOCHARGER

13

1246 466 H1

SHIELD, HEAT

14

1246 479 H1

SEAL, SPLIT RING

15

1246 477 H1

RING, RETAINING

16

1246 476 H1

BEARING, THRUST

17

1246 465 H1

BOLT

18

1294 189 H1

PLATE, CLAMPING

19

1294 190 H1

O-RING

20

1246 482 H1

NUT,LOCK

21

1246 462 H1

SLINGER, OIL

22

1294 191 H1

IMPELLER, TURBO

23

1294 192 H1

SHAFT AND WHEEL

24

1294 193 H1

COLLAR, THRUST

25

1246 470 H1

WASHER, LOCK

26

1246 481 H1

BOLT

27

1246 488 H1

GASKET, TURBOCHARGER

28

1294 088 H1

GASKET, TURBOCHARGER

29

1294 260 H1

GASKET, TURBOCHARGER

|$30

1240 519 H91

KIT, STUD

30

1240 550 H1

NUT

31

1240 549 H1

STUD

|$33

1294 227 H91

KIT, TURBO REPAIR

7

1246 484 H1

RING, RETAINING

9

1246 480 H1

SEAL, SPLIT RING

12

1246 468 H1

BEARING, TURBOCHARGER

14

1246 479 H1

SEAL, SPLIT RING

15

1246 477 H1

RING, RETAINING

16

1246 476 H1

BEARING, THRUST

17

1246 465 H1

BOLT

19

1294 190 H1

O-RING

25

1246 470 H1

WASHER, LOCK

26

1246 481 H1

BOLT

|$44

1294 243 H91

KIT, TURBOCHARGER GASKET

27

1246 488 H1

GASKET, TURBOCHARGER

28

1294 088 H1

GASKET, TURBOCHARGER

29

1294 260 H1

GASKET, TURBOCHARGER
