Запчасти Komatsu PC400LC-5 ГОЛОВКА ЦИЛИНДРОВ ГОЛОВКА ЦИЛИНДРОВ

|$0

1296 478 H91

HEAD, CYLINDER

1

NSS

HEAD, CYLINDER

2

1239 144 H1

PLUG, EXPANSION

3

1246 425 H1

PLUG, EXPANSION

4

1246 113 H1

PLUG, EXPANSION

5

1239 149 H1

O-RING

6

1241 724 H1

SLEEVE, INJECTOR

7

1246 427 H1

INSERT, VALVE - EXHAUST

8

1296 486 H1

INSERT, VALVE - INTAKE

9

1296 073 H1

GUIDE, VALVE STEM

10

1246 161 H1

BOLT, W/WASHER

11

1296 481 H1

SPRING, VALVE

12

1246 430 H1

PLATE, COVER

13

1294 178 H1

GASKET, COVER PLATE

|$14

1296 642 H91

VALVE, INTAKE

14

NSS

VALVE, INTAKE

15

139 850

COLLET, VALVE

|$17

1296 641 H91

VALVE, EXHAUST

15

139 850

COLLET, VALVE

16

NSS

VALVE, EXHAUST

17

1296 488 H1

RETAINER, VALVE SPRING

18

1296 489 H1

GUIDE, SPRING

19

1240 101 H1

PLUG, PIPE

20

1294 177 H1

PLUG, ORIFICE

21

1296 074 H1

SEAL, VALVE STEM - INTAKE

22

1296 075 H1

SEAL, VALVE STEM - EXHAUST

23

1294 173 H1

SCREW, HEX FLANGE HEAD CAP

24

1294 172 H1

BOLT

25

1296 076 H1

GASKET, CYLINDER HEAD

26

1294 090 H1

WASHER, PLAIN

27

1246 440 H1

SCREW, TWELVE POINT CAP

|$31

1296 077 H1

GUIDE, VALVE STEM - 0.20 MM O/S

|$32

1246 640 H1

INSERT, VALVE - 0.25 MM O/S

|$33

1246 641 H1

INSERT, VALVE - 0.50 MM O/S

|$34

1246 642 H1

INSERT, VALVE - 0.75 MM O/S

|$35

1246 643 H1

INSERT, VALVE - 1.00 MM O/S
