Запчасти Komatsu PC400LC-5 ЭЛЕКТРИКА ЭЛЕКТРОПРОВОДКА ГЕНЕРАТОР, CRANKING МОТОР И ДАТЧИКS КОМПОНЕНТЫ ДВИГАТЕЛЯ & ЭЛЕКТРИКА

1

208-06-58142

HARNESS, WIRING (TO ALTERNATOR, CRANKING MOTOR

2

08036-01814

CLIP

|$3

01010-51225

BOLT

|$4

01643-31232

WASHER

3

08038-02027

CAP

4

08036-01814

CLIP

|$7

01010-51025

BOLT

|$8

01643-31032

WASHER

5

208-06-58220

BRACKET

|$10

01010-51085

BOLT

|$11

01643-31032

WASHER

6

08036-01014

CLIP

|$13

01010-51025

BOLT

|$14

01643-31032

WASHER

7

208-06-58131

HARNESS, WIRING (TO SHUT-OFF VALVE, OIL LEVEL

8

08036-01214

CLIP

|$18

01010-51225

BOLT

|$19

01643-31232

WASHER

9

08036-91214

CLIP

|$21

01010-51020

BOLT

|$22

01643-31032

WASHER

10

08036-91014

CLIP

|$24

01010-51020

BOLT

|$25

01643-31032

WASHER

11

08038-10525

CAP

12

208-06-58210

BRACKET

|$28

01010-51020

BOLT

|$29

01643-31032

WASHER

13

208-06-58190

WIRE

14

08038-00035

CAP

15

20Y-06-18170

WIRE

16

20Y-06-18180

WIRE

17

08038-00525

CAP

22

7861-92-4520

SENSOR

|$40

07002-23634

O-RING

23

208-01-A1100

BRACKET, SWITCH

24

01435-00816

BOLT

25

203-06-59320

SWITCH

26

208-06-58150

BRACKET

|$45

01010-51220

BOLT

|$46

01643-31232

WASHER

27

206-01-A1130

SENSOR, TEMPERATURE

28

206-01-A1140

SENSOR, OIL LEVEL

29

206-01-A1150

SWITCH, OIL PRESSURE

|$50

444 024

BUSHING, PIPE
