Запчасти Komatsu PC400LC-5 МОТОР ПОВОРОТА ТОРМОЗ. КОРПУС УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

|$0

706-77-01162

MOTOR ASSEMBLY, SWING

1

706-77-43191

BLOCK, CYLINDER

2

706-77-42160

PISTON SUB ASSEMBLY

3

706-77-42081

SHAFT, CENTER

4

706-77-42110

SPRING

5

706-77-43130

RING, CENTER

6

706-77-42071

BUSHING

7

706-77-43850

PLATE, VALVE

8

04020-01024

PIN, DOWEL

9

706-77-42260

RETAINER

10

706-77-42861

SHAFT

11

706-75-41271

SCREW

12

706-77-42022

CASE, BRAKE

13

706-77-42881

BEARING

14

706-77-42890

BEARING

15

706-77-42041

SEAT

16

706-77-42051

SPRING

17

706-77-42440

SPACER, 0.090 IN (2.3 mm)

|$18

706-77-42450

SPACER, 0.098 IN (2.5 mm)

|$19

706-77-42460

SPACER, 0.106 IN (2.7 mm)

18

04064-06525

RING, SNAP

19

706-77-42060

COVER

20

07000-02115

O-RING

21

706-77-43950

SEAL, OIL

22

04071-00130

RING, SNAP

23

706-77-91331

PLATE

24

706-77-91341

PLATE

25

706-77-91350

DISC

26

706-77-91490

PISTON, BRAKE

27

07000-15200

O-RING

28

07001-05200

RING, BACK-UP

29

07000-15220

O-RING

30

07001-05220

RING, BACK-UP

31

07000-05250

O-RING

32

706-77-91410

SPRING

33

706-75-42830

PIN, DOWEL

34

01010-51860

BOLT

35

01602-21854

WASHER, SPRING
