Запчасти Komatsu PC400LC-5 P.P.C. КЛАПАН ДЛЯ РАБОЧ. ОБОРУД-Я УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

|$0

702-16-32001

VALVE ASSEMBLY, WORK EQUIPMENT P.P.C

1

NSS

BODY, VALVE

2

07043-50312

PLUG

3

NSS

VALVE

4

702-16-51510

SPRING, INNER

5

702-16-51140

SHIM, 1/64 IN (0.3 mm)

6

702-16-52260

SPRING, OUTER

7

702-16-52250

SPRING, OUTER

8

702-16-51832

RETAINER

9

702-16-51170

COLLAR

10

702-16-52270

PISTON

11

702-16-52290

SPRING

12

702-16-52221

PISTON

13

702-16-52170

COLLAR

14

07000-02021

O-RING

15

702-16-51270

SEAL

16

702-16-52162

COLLAR

17

702-16-52190

SEAL, DUST

18

702-16-52180

PLATE

19

702-16-52212

JOINT

20

702-16-51820

DISK

21

01583-11811

NUT

22

01010-50816

BOLT

23

01643-30823

WASHER

24

702-16-51890

FILTER, P.P.C. VALVE FOR WORK EQUIPMENT

25

07002-02034

O-RING
