ПЕЧКА

Запчасти Komatsu PC400LC-5 ПЕЧКА ЧАСТИ КОРПУСА

Схема запчастей Komatsu PC400LC-5 - ПЕЧКА ЧАСТИ КОРПУСА
12
18
11
13
9
8
10
15
16
20
7
14
4
19
15
2
17
3
6
1
5
15
15
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

|$0

205-977-7110

HEATER ASSEMBLY

1

ND116460-2562

CASE, BOTTOM

2

ND116460-2572

CASE, TOP

3

ND116410-2841

RADIATOR

4

ND146371-3500

COVER

5

ND146681-7711

CLAMP

6

ND91570-06141

BOLT AND WASHER

7

ND062500-3731

MOTOR, CAB HEATER

8

ND949007-0240

SCREW AND WASHER

9

ND949194-0040

PLATE

10

ND949197-0180

RUBBER

11

ND116221-0460

BLOWER

12

ND949056-2230

NUT

13

ND949011-7650

WASHER

14

ND949321-2630

GROMMET

15

ND949001-1820

SCREW

16

ND146640-3461

PLATE

17

ND146741-2170

PRODUCT GRAPHICS, OPERATING INSTRUCTIONS

18

ND146713-1372

PRODUCT GRAPHICS, CAUTION

19

ND146659-1350

INSULATION

20

ND146820-2171

RESISTOR

N/I

ND116253-0440

GUIDE

N/I

ND116403-0620

LETTERSTYLE
