Запчасти Komatsu PC400LC-5 КАБИНА ASSEMBLY COMPLETE ASSEMBLY ЧАСТИ КОРПУСА

|$0

207-54-00062

CAB ASSEMBLY

1

NSS

CAB

2

20Y-54-11262

COVER, TOP

3

20Y-54-11282

HINGE

4

01435-00616

SCREW

5

20Y-54-14590

HANDLE

6

01220-40610

SCREW

7

01602-20619

WASHER, SPRING

8

01641-20608

WASHER

9

20Y-54-14630

SEAL

10

205-54-63650

SPRING ASSEMBLY, TOP GAS

11

04205-10825

PIN

12

04052-10833

PIN

13

20Y-54-11383

BRACKET

14

01435-00616

BOLT

15

20Y-54-13492

BRACKET

16

01435-00616

BOLT

17

20Y-54-14321

LOCK ASSEMBLY, CAB TOP COVER

18

20Y-54-14370

BOLT

|$19

20Y-54-11890

LOCK ASSEMBLY, CAB DOOR OPEN RETAINER

19

20Y-54-13530

LOCK

20

20Y-54-13540

LEVER

21

20Y-54-13550

SPRING

22

20Y-54-13560

PIN

23

01580-10605

NUT

24

01602-20619

WASHER, SPRING

25

20Y-54-14530

PLATE

26

01010-50825

BOLT

27

01643-30823

WASHER

28

20Y-54-11490

BRACKET

29

01370-00412

SCREW

30

20Y-54-11611

STOPPER

31

01580-11008

NUT

32

20Y-54-11750

SEAT

33

205-54-71731

STRIKER

34

20Y-54-11740

SCREW

35

20Y-54-14480

BRACKET, L.H

36

20Y-54-14490

BRACKET, R.H

37

01010-50825

BOLT

38

01643-30823

WASHER

39

205-54-71560

TRIM

40

01010-51016

BOLT

N/I

20Y-54-14170

SCREW, DOOR MOUNTING
