Запчасти Komatsu PC400-8R ЦИЛИНДР СТРЕЛЫ, ЛЕВ. (№7-) ЦИЛИНДР СТРЕЛЫ, ДЛЯ ПОГРУЗ.

|$0

707-01-0G350

Cylinder Assembly

1

707-13-16960

Cylinder

2

707-58-11620

Rod

3

707-76-10270

Bushing

4

07145-00100

Seal, Dust, (Kit : K06)

5

07020-00000

Fitting, Grease

6

707-76-10130

Bushing

7

07145-00100

Seal, Dust, (Kit : K06)

8

707-71-71610

Collar

9

707-35-91640

Ring, Back-up, (Kit : K06)

10

07000-15150

O-ring, (Kit : K06)

11

707-71-61140

Plunger

12

707-27-16580

Head

13

707-56-11740

Seal, Dust, (Kit : K06)

14

07179-13126

Ring, Snap

15

707-52-90851

Bushing

16

707-51-11030

Packing, Rod, (Kit : K06)

17

707-51-11640

Ring, Buffer, (Kit : K06)

18

707-35-91640

Ring, Back-up, (Kit : K06)

19

07000-15150

O-ring, (Kit : K06)

20

707-88-81530

Bolt

21

707-88-75310

Washer

22

707-75-11040

Ring, Snap

23

707-36-16580

Piston

24

707-44-16180

Ring, Piston, (Kit : K06)

25

707-39-16120

Ring, Wear, (Kit : K06)

26

707-44-16910

Ring

27

07000-15100

O-ring, (Kit : K06)

28

07001-05100

Ring, Back-up, (Kit : K06)

29

01310-01216

Screw

30

707-86-12790

Tube

31

707-86-00930

Tube

32

707-87-14700

Plug

33

07002-63034

O-ring, (Kit : K06)

34

07372-21060

Bolt

35

01643-51032

Washer

36

07000-13035

O-ring, (Kit : K06)

37

707-88-25370

Bracket

38

707-88-21660

Band

39

07372-21240

Bolt

40

01643-51232

Washer

41

07283-33442

Clip, Pipe

42

01643-31032

Washer

43

01597-01009

Nut

44

01010-81025

Bolt

45

01643-31032

Washer

46

707-88-33040

Cap

47

07371-31049

Flange, Split

48

07372-21035

Bolt

49

01643-51032

Washer
