Запчасти Komatsu PC400-8 РУКОЯТЬ, ЦИЛИНДР ЛЕВ. (№7-) РУКОЯТЬ, ПРЯМАЯ ЛОПАТА CONFIGURATION

|$0

707-01-0G380

Cylinder Assembly

1

707-13-13810

Cylinder

2

707-58-95240

Rod

3

707-76-80010

Bushing

4

07145-00080

Seal, Dust, (Kit : K11)

5

707-76-10130

Bushing

6

07145-00100

Seal, Dust, (Kit : K11)

7

07020-00675

Fitting, Grease

8

707-27-13640

Head

9

707-56-95740

Seal, Dust, (Kit : K11)

10

07179-13109

Ring, Snap

11

707-52-90711

Bushing

12

707-51-95030

Packing, Rod, (Kit : K11)

13

707-51-95640

Ring, Buffer, (Kit : K11)

14

07001-05130

Ring, Back-up, (Kit : K11)

15

07000-15130

O-ring, (Kit : K11)

16

01010-81875

Bolt

17

707-41-11840

Washer

18

707-75-95030

Ring, Snap

19

707-36-13771

Piston

20

707-44-13280

Ring, Piston, (Kit : K11)

21

707-39-13530

Ring, Wear, (Kit : K11)

22

707-44-13920

Ring

23

01310-01216

Screw

24

07000-15085

O-ring, (Kit : K11)

25

707-35-90960

Ring, Back-up, (Kit : K11)

26

707-86-67260

Tube

27

208-63-74380

Tube

28

07372-21060

Bolt

29

01643-51032

Washer

30

07372-21045

Bolt

31

01643-51032

Washer

32

07372-21035

Bolt

33

01643-51032

Washer

34

07372-21235

Bolt

35

01643-51232

Washer

36

707-88-25640

Bracket

37

707-88-21570

Band

38

707-88-25830

Bracket

39

707-88-21980

Band

40

01643-31032

Washer

41

01597-01009

Nut

42

07283-33442

Clip, Pipe

43

707-88-33030

Cap

44

07371-30640

Flange, Split

45

07372-21035

Bolt

46

01643-51032

Washer

47

707-88-33040

Cap

48

07371-31049

Flange, Split

49

07283-32738

Clip, Pipe

50

07000-13030

O-ring, (Kit : K11)

51

07000-13035

O-ring, (Kit : K11)
