Запчасти Komatsu PC400-7E0 НИЖН. ГИДРОЦИЛИНДР КОВША (ДЛЯ ПОГРУЗ.) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XT380

CYLINDER ASS'Y,L.H. (FINAL COATING)

G-2

707-01-XT390

CYLINDER ASS'Y,R.H. (FINAL COATING)

|$5

707-01-0G400

CYLINDER ASS'Y

1

707-13-13820

CYLINDER

2

707-76-80010

BUSHING

3

07145-00080

SEAL,DUST (KIT)

4

07020-00000

FITTING,GREASE

5

707-58-90E10

ROD,PISTON

6

205-63-65271

BUSHING

7

07145-00080

SEAL,DUST (KIT)

8

707-27-13650

HEAD,CYLINDER

9

707-52-90680

BUSHING

10

707-51-90030

PACKING,ROD (KIT)

11

707-51-90640

RING,BUFFER (KIT)

12

707-75-90110

RING,SNAP

13

195-63-94170

SEAL,DUST (KIT)

14

07179-13104

RING,SNAP

15

07000-15120

O-RING (KIT)

16

707-35-91320

RING,BACK-UP (KIT)

17

01010-81670

BOLT

18

01643-51645

WASHER

19

707-36-13780

PISTON

20

707-44-13180

RING,PISTON (KIT)

21

707-39-13150

RING,WEAR (KIT)

22

707-44-13911

RING

23

07000-15080

O-RING (KIT)

24

707-35-90940

RING,BACK-UP (KIT)

25

01310-01216

SCREW

26

707-86-67280

TUBE,L.H.

26

707-86-67290

TUBE,R.H.

27

208-63-94380

TUBE,L.H.

27

208-63-94480

TUBE,R.H.

28

07372-21060

BOLT

29

01643-51032

WASHER

30

07372-21045

BOLT

31

01643-51032

WASHER

32

07000-13030

O-RING (KIT)

33

707-88-25820

BRACKET

34

707-88-87280

BRACKET

35

707-88-87270

BAND

36

07372-21035

BOLT

37

01643-51032

WASHER

38

07282-12793

CLAMP

39

01010-81020

BOLT

40

01643-31032

WASHER

41

707-88-33030

CAP

42

07371-30640

FLANGE,SPLIT

43

07372-21035

BOLT

44

01643-51032

WASHER

|$53

707-99-47800

SERVICE KIT
