Запчасти Komatsu PC400-7E0 ЦИЛИНДР РУКОЯТИ(ДЛЯ ПОГРУЗ.) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XT350

ARM CYLINDER GROUP,(FINAL COATING)

|$3

707-01-0G370

CYLINDER ASS'Y

1

707-13-18830

CYLINDER

2

707-76-11130

BUSHING

3

07145-00110

SEAL,DUST (KIT)

4

707-58-12300

ROD

5

707-76-11130

BUSHING

6

07145-00110

SEAL,DUST (KIT)

7

707-71-60310

PLUNGER

8

04260-01270

BALL

9

707-71-91520

CAP

10

707-27-18930

HEAD

11

195-63-93170

SEAL,DUST (KIT)

12

07179-13136

RING,SNAP

13

707-52-90980

BUSHING

14

07179-13126

RING,SNAP

15

707-51-12030

PACKING,ROD (KIT)

16

707-51-12640

RING,BUFFER (KIT)

17

707-35-91840

RING,BACK-UP (KIT)

18

07000-15175

O-RING (KIT)

19

01011-82400

BOLT

20

707-88-75410

WASHER

21

707-36-18520

PISTON

22

01310-01225

SCREW

23

707-44-18280

RING,PISTON (KIT)

24

707-39-18510

RING,WEAR (KIT)

25

707-44-18920

RING

26

07001-05110

RING,BACK-UP (KIT)

27

07000-15110

O-RING (KIT)

28

707-86-12810

TUBE

29

707-86-12820

TUBE

30

07372-21060

BOLT

31

01643-51032

WASHER

32

07372-21060

BOLT

33

01643-51032

WASHER

34

07000-13035

O-RING (KIT)

35

707-88-25620

BRACKET

36

707-88-21880

BAND

37

07372-21240

BOLT

38

01643-51232

WASHER

39

07283-33442

CLIP

40

01643-31032

WASHER

41

01597-01009

NUT

42

707-88-25630

BRACKET

43

707-88-21930

BAND

44

07372-21240

BOLT

45

01643-51232

WASHER

46

707-88-33040

CAP

47

07371-31049

FLANGE,SPLIT

48

07372-21035

BOLT

49

01643-51032

WASHER

|$54

707-99-68780

SERVICE KIT
