Запчасти Komatsu PC400-7 ОХЛАЖД-Е (КРЫШКАAND ЩИТКИ) C СИСТЕМА ОХЛАЖДЕНИЯ
37
36
18
16
17
14
36
37
20
21
19
15
39
39
32
33
40
40
25
26
22
23
24
35
34
31
30
29
28
27
12
13
9
8
10
11
38
41
1
5
4
6
7
3
2
1
208-03-71410
SEAL
2
208-03-71421
COVER
3
208-03-71511
SEAL
4
208-03-71541
SEAL
5
208-03-71550
SEAL
6
01010-81225
BOLT
7
01643-31232
WASHER
8
208-03-71431
COVER
9
208-03-71521
SEAL
10
208-03-71541
SEAL
11
208-03-71560
SEAL
12
01010-81225
BOLT
13
01643-31232
WASHER
14
208-03-71441
COVER
15
208-03-71571
SEAL
16
208-03-71580
SEAL
17
208-03-71591
SEAL
18
208-03-71610
SEAL
19
208-03-71670
SEAL
20
01010-81225
BOLT
21
01643-31232
WASHER
22
208-03-71451
COVER
23
208-03-71621
SEAL
24
208-03-71631
SEAL
25
01010-81225
BOLT
26
01643-31232
WASHER
27
208-03-71462
COVER
28
208-03-71641
SEAL
29
208-03-71650
SEAL
30
01010-81225
BOLT
31
01643-31232
WASHER
32
208-03-71471
COVER
33
208-03-71661
SEAL
34
01010-81225
BOLT
35
01643-31232
WASHER
36
01010-81640
BOLT
37
01643-31645
WASHER
38
208-03-72110
SHEET
39
208-03-71980
SHEET
40
208-03-71990
SHEET
41
208-03-72120
SHEET
