Запчасти Komatsu PC400-7 ГЕНЕРАТОР (A)(ВНУТР. ЧАСТИS) AA ДВИГАТЕЛЬ [SAADE- заводской номер -UP]

|$1

600-825-3151

ALTERNATOR A (35A)

1

KD0-35100-0280

ROTOR ASS'Y

2

KD1-33923-0790

COLLAR

3

KD0-09201-0870

BEARING,BALL

4

KD0-35200-0400

STATOR ASS'Y

5

KD0-35300-0130

FRONT BRACKET ASS'Y

6

KD0-09201-0881

BEARING,BALL

7

KD0-35926-0070

RETAINER

8

KD0-35951-0060

PACKING

9

KD0-35926-0090

RETAINER

10

KD1-33926-0730

RETAINER

11

KD0-0275-06802

BOLT

12

KD0-35411-0560

PULLEY

13

KD0-35421-0140

FAN

14

KD1-0335-16002

WASHER,SPRING

15

KD0-0280-16022

NUT

16

KD0-35120-0450

FIELD COIL

|$18

KD0-35700-0662

REAR BRACKET ASS'Y

17

KD0-35710-0751

BRACKET,REAR

18

KD0-35730-0510

RECTIFIER ASS'Y

19

KD0-09170-2501

CONDENSER

20

KD0-35943-0150

BUSH,INSULATE

21

KD0-35923-0130

COLLAR

22

KD0-35943-0160

BUSH,INSULATE

23

KD0-35943-0140

BUSH,INSULATE

24

KD0-35943-0170

BUSH,INSULATE

25

KD0-35784-0280

BAR,CONNECT

26

KD0-35784-0270

TERMINAL,PLATE

27

KD0-35719-0151

REGULATOR ASS'Y

28

KD0-35761-0181

COVER
