Запчасти Komatsu PC400-7 МОТОР ХОДА (/) Y РЕМ. КОМПЛЕКТЫ И COMPONENT

|$1

706-8J-01012

MOTOR ASS'Y

1

706-8J-41110

CASE, MOTOR

|$5

706-8J-00012

AND COVER SUB ASS'Y

2

COVER AND

|$7

PLATE ASS'Y, VALVE

3

PLATE VALVE

4

BUSHING

5

BLOCK, CYLINDER

6

SPOOL

7

PLUG

8

706-86-71310

PIN DOWEL

9

706-8E-14191

PLUG

10

07002-11823

O-RING

11

706-8J-71550

PISTON

12

706-8J-71560

PIN DOWEL

13

706-8J-71130

PLUG

14

07002-12434

O-RING

15

706-8J-71140

PLUG

16

07002-12434

O-RING

17

20B-27-11210

BLEEDER

18

706-75-74540

VALVE

19

706-75-74550

SPRING

20

706-75-74850

PLUG

21

07002-13334

O-RING

22

708-8F-36120

RING

23

706-78-71280

SPRING

24

706-78-71230

PLUG

25

07002-13634

O-RING

26

706-8E-14170

SPRING

27

706-8J-71150

SPOOL

28

706-8J-71160

PLUG

29

07002-11823

O-RING

30

706-86-53410

VALVE

31

706-8J-71170

PLUG

32

07002-11023

O-RING

33

708-8E-16180

VALVE

34

706-8J-71180

VALVE

35

708-8E-16160

PLUG

36

07002-11023

O-RING

37

708-8J-71190

PLUG

38

07002-11223

O-RING

39

07000-15270

O-RING

40

07000-12012

O-RING

41

01252-62060

BOLT
