Запчасти Komatsu PC400-7 ОСНОВН. НАСОС (7/) Y РЕМ. КОМПЛЕКТЫ И COMPONENT

|$1

708-2H-00022

PUMP ASS'Y

|$4

708-2H-01022

PUMP SUB ASS'Y

1

708-2H-32121

SHAFT

2

708-1H-22150

BEARING

3

708-17-05010

WASHER KIT

|$8

WASHER, 30MM

|$9

WASHER, 31MM

|$10

WASHER, 32MM

4

708-17-12780

RING, SNAP

|$12

708-2H-04650

BLOCK ASS'Y REAR

5

BLOCK, CYLINDER

6

PLATE, VALVE

7

708-18-13230

PIN

8

04065-05820

RING

9

708-2H-33140

SEAT

10

708-2H-33150

SPRING

11

708-2H-23141

SEAT

12

708-2H-23350

GUIDE, RETAINER

13

708-2H-23360

PIN

14

708-2H-33342

RETAINER, SHOE

15

708-2H-33311

PISTON SUB ASS'Y

|$24

708-2H-04630

CRADLE SUB ASS'Y

16

CRADLE

17

CAM, ROCKER

18

04020-01434

PIN DOWEL

19

07000-B1009

O-RING

20

01252-61235

BOLT

21

708-2H-32130

COUPLING

22

708-2H-12420

RING
