Запчасти Komatsu PC400-7 БЛОК ЦИЛИНДРОВ AA ДВИГАТЕЛЬ [SAADE- заводской номер -UP]

|$1

6154-21-1100

CYLINDER BLOCK ASS'Y

1

BLOCK CYLINDER

2

6150-21-1490

BUSHING,CAMSHAFT

3

6150-29-1210

CAP,MAIN METAL, NO1,2,3,4,5,6

4

6150-29-1250

CAP,MAIN METAL, NO7

5

04020-00514

PIN,DOWEL

6

6150-21-1710

BOLT

7

01643-31645

WASHER

8

07043-50108

PLUG

9

07043-50211

PLUG

10

07043-50617

PLUG

11

07040-12414

PLUG

12

07040-13016

PLUG

13

07002-23034

O-RING (K2)

14

07002-22434

O-RING (K2)

15

07046-43016

PLUG

16

07046-44016

PLUG

17

6154-21-1981

PLUG

18

07000-72022

O-RING

19

07046-21210

PLUG

20

07046-43516

PLUG

21

04020-00820

PIN,DOWEL

22

6150-21-1170

TUBE

23

6150-41-2430

PIN

24

6150-41-2440

PIN

25

04025-00408

PIN,ROLL

26

6150-21-4770

PIN,DOWEL

27

6150-41-2430

PIN

28

04020-01024

PIN,DOWEL

29

04025-00512

PIN,SPRING

30

6154-21-2220

LINER,CYLINDER

31

6150-21-2230

O-RING,LOWER (K2)

32

6150-21-2240

O-RING,CENTER (K2)

33

6150-21-2250

SEAL,CREVICE (K2)

34

6154-21-1810

NOZZLE,PISTON COOLING

35

01435-00816

BOLT
