Запчасти Komatsu PC400-7 ГИДР. БАК. H ГИДРАВЛИКА

1

208-60-71113

TANK

2

203-60-31100

ELBOW ASS'Y

3

203-60-31160

TUBE

4

07044-12412

PLUG

5

07002-12434

O-RING

6

02783-10628

ELBOW

7

07002-12434

O-RING

8

02896-11018

O-RING

9

02782-10315

ELBOW

10

07002-12034

O-RING

11

02896-11009

O-RING

12

207-62-72110

UNION

13

07002-13334

O-RING

14

207-62-64740

O-RING

15

02782-10315

ELBOW

16

07002-12034

O-RING

17

02896-11009

O-RING

18

02783-10210

ELBOW

19

07002-11423

O-RING

20

02896-11008

O-RING

21

208-60-71120

ELEMENT

22

07069-25400

STRAINER

23

208-60-71160

VALVE ASS'Y

24

07069-34075

SPRING

25

208-60-71130

PLATE

26

07000-15210

O-RING

27

01010-81225

BOLT

28

01643-31232

WASHER

|$29

208-60-71140

STRAINER ASS'Y

29

208-60-71150

ROD ASS'Y

30

12R-60-11230

SPRING

31

20Y-60-21320

HOLDER

32

22B-60-11160

STRAINER

33

208-60-61190

COVER

34

07000-15180

O-RING

35

01010-81225

BOLT

36

01643-31232

WASHER

37

198-60-55510

BREATHER, (SEE FIG Y1890-01A0)

38

17A-60-11310

CAP ASS'Y

39

20Y-60-21470

ELEMENT

40

20Y-60-21460

NECK

41

20Y-60-21340

GASKET

42

01252-70516

BOLT

43

01601-20513

WASHER

44

07285-00155

CLIP

45

07270-61420

TUBE

46

07056-10045

STRAINER

47

04065-04718

RING

48

208-60-71250

SHEET

49

01010-81635

BOLT

50

01643-31645

WASHER

51

195-03-11570

SHIM, 10MM
