Запчасти Komatsu PC400-7 ПОРШЕНЬ НАСОС (7/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$4

708-2H-00450

PUMP ASS'Y

|$5

708-2H-00027

PUMP ASS'Y

|$6

708-2H-00026

PUMP ASS'Y

|$7

708-2H-00022

PUMP ASS'Y

|$9

708-2H-01450

PUMP SUB ASS'Y

|$10

708-2H-01027

PUMP SUB ASS'Y

|$11

708-2H-01026

PUMP SUB ASS'Y

|$12

708-2H-01022

PUMP SUB ASS'Y

1

708-2H-32210

SHAFT

1

708-2H-32121

SHAFT

2

708-1H-22150

BEARING

3

708-17-05010

WASHER KIT

3

WASHER, 3.0MM

3

WASHER, 3.1MM

3

WASHER, 3.2MM

4

708-17-12780

RING,SNAP

|$21

708-2H-04760

BLOCK ASS'Y,REAR

|$22

708-2H-04650

BLOCK ASS'Y,REAR

5

BLOCK,CYLINDER

5

BLOCK,CYLINDER

6

PLATE,VALVE

7

708-18-13230

PIN

8

04065-05820

RING

9

708-2H-33140

SEAT

10

708-2H-33150

SPRING

11

708-2H-23141

SEAT

12

708-2H-23350

GUIDE,RETAINER

13

708-2H-23360

PIN

14

708-2H-33343

RETAINER,SHOE

14

708-2H-33342

RETAINER,SHOE

15

708-2H-33311

PISTON SUB ASS'Y

|$36

708-2H-04690

CRADLE SUB ASS'Y

|$37

708-2H-04630

CRADLE SUB ASS'Y

16

CRADLE

16

CRADLE

17

CAM,ROCKER

17

CAM,ROCKER

18

04020-01434

PIN,DOWEL

19

07000-B1009

O-RING

20

01252-61235

BOLT

21

708-2H-32130

COUPLING

22

708-2H-12420

RING
