Запчасти Komatsu PC400-7 ЦИЛИНДР КОВША (СПЕЦ-Я -40С)(№-9) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XT250

CYLINDER GROUP,(FINAL COATING)

|$3

707-01-0G280

CYLINDER ASS'Y

1

707-13-16870

CYLINDER

2

707-76-10130

BUSHING

3

07145-10100

SEAL,DUST (KIT)

4

07020-00000

FITTING,GREASE

5

707-58-10970

ROD

6

707-76-10140

BUSHING

7

208-70-73530

SEAL,DUST (KIT)

8

07020-00000

FITTING,GREASE

9

707-27-16950

HEAD

10

176-63-56170

SEAL,DUST (KIT)

11

07179-13114

RING,SNAP

12

707-52-90780

BUSHING

13

707-75-10160

RING,SNAP

14

707-51-10730

PACKING,ROD (KIT)

15

707-51-10640

RING,BUFFER (KIT)

16

707-35-91640

RING,BACK-UP (KIT)

17

07000-55150

O-RING (KIT)

18

01010-82085

BOLT

19

707-88-75310

WASHER

20

707-36-16580

PISTON

21

01310-01216

SCREW

22

707-44-16180

RING,PISTON (KIT)

23

707-39-16120

RING,WEAR (KIT)

24

707-44-16910

RING

25

07001-05100

RING,BACK-UP (KIT)

26

07000-55100

O-RING (KIT)

27

707-11-31980

PLATE

28

707-86-12580

TUBE

29

707-86-12570

TUBE

30

07372-21060

BOLT

31

01643-51032

WASHER

32

07000-53035

O-RING (KIT)

33

707-88-25390

BRACKET

34

07372-21240

BOLT

35

01643-51232

WASHER

36

707-88-10150

CLAMP

37

01010-81245

BOLT

38

01643-31232

WASHER

39

707-88-33040

CAP

40

07371-31049

FLANGE,SPLIT

41

07372-21035

BOLT

42

01643-51032

WASHER

|$47

707-99-66260

SERVICE KIT
