Запчасти Komatsu PC400-6Z ОСНОВН. НАСОС (9/9)(№-999) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

708-2H-00120

PUMP ASS'Y

|1

708-2H-03120

SERVO VALVE ASS'Y

|1

708-2H-03800

BODY ASS'Y

1

BODY

2

PLUG

3

EXPANDER

4

708-2L-25480

FILTER

5

708-2L-25490

O-RING

6

708-2L-25631

SPACER

7

708-2H-25650

ORIFICE

8

07000-B2110

O-RING

9

708-8E-16150

PLUG

10

07002-61023

O-RING

11

708-2L-25211

SOLENOID ASS'Y

12

07000-B2016

O-RING

13

01252-60612

BOLT

14

708-2L-25223

SLEEVE

15

708-2L-25232

SPOOL

16

708-2L-25291

SEAT

17

708-2H-25250

SPRING

18

708-2L-25261

SPRING

19

708-2L-25281

PISTON

20

07040-11007

PLUG

21

07002-61023

O-RING

22

708-2H-25370

LEVER

23

708-2L-25311

PIN

24

708-2L-25330

BEARING

25

708-2L-25321

WASHER

26

01580-00605

NUT

27

708-2L-25340

PLUG

28

01583-11811

NUT

29

07002-61823

O-RING

30

708-2L-25382

PLUG

31

07000-B2010

O-RING

32

04065-01610

RING,SNAP

33

708-2L-25731

SPOOL

34

708-2L-25521

SLEEVE

35

708-2L-25531

PLUG

36

07002-62034

O-RING

37

708-2L-25542

SEAT

38

708-2L-25551

SPRING

39

708-2H-25620

PLUG

40

708-2L-25611

PISTON

41

708-2L-25640

SEAT

42

07001-02012

RING,BACK-UP

43

07000-B2012

O-RING

44

01583-12012

NUT
