Запчасти Komatsu PC400-6Z ПРАВ. ДВЕРЬ (КАБИНА)(№-8) ЧАСТИ КОРПУСА

1

207-54-61210

COVER

2

20Y-54-28161

HINGE (WELDED)

3

198-54-41982

LOCK ASS'Y (WELDED)

4

207-54-61151

COVER

5

20Y-54-28161

HINGE (WELDED)

6

198-54-41982

LOCK ASS'Y (WELDED)

7

205-54-53550

DOVE TAIL

8

01010-50612

BOLT

9

01643-30623

WASHER

10

208-54-61231

FRAME,R.H.

11

20Y-54-28170

BRACKET

12

01010-51230

BOLT

13

01643-31232

WASHER

14

205-54-51970

DOVE TAIL

15

01010-50616

BOLT

16

01643-30623

WASHER

17

20Y-54-28182

PLATE

17

20Y-54-28181

PLATE

18

01010-51230

BOLT

19

01643-31232

WASHER

20

20Y-54-29232

BAR

21

20Y-54-29251

SEAL

22

20Y-54-29261

SEAL

23

203-54-56710

STOPPER

24

01580-11008

NUT

25

207-54-61141

PLATE

26

01010-51225

BOLT

27

01643-51232

WASHER

28

20Y-54-29232

BAR

29

20Y-54-29261

SEAL

30

207-54-61260

SEAL

31

203-54-56710

STOPPER

32

01580-11008

NUT

33

01010-51235

BOLT

34

01643-31232

WASHER

35

20Y-54-28290

PLATE

36

208-54-61121

COVER,R.H.

37

01010-51230

BOLT

38

01643-31232

WASHER

39

20Y-54-12920

CLAMP

40

01010-51025

BOLT

41

01643-31032

WASHER

42

01010-51230

BOLT

43

01643-31232

WASHER

44

207-54-61860

BRACKET

45

203-54-63230

CLAMP

46

01220-40612

SCREW

47

01641-20608

WASHER

48

01010-51230

BOLT

49

01643-31232

WASHER
