Запчасти Komatsu PC400-6C ОСНОВН. КЛАПАН (-АКТУАТОР) (/) (- DEG. СПЕЦ-Я.)(№9-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$6

723-47-17300

CONTROL VALVE

|$7

723-47-17204

CONTROL VALVE

|$8

723-47-17203

CONTROL VALVE

|$9

723-47-17202

CONTROL VALVE

|$10

723-47-17201

CONTROL VALVE

|$11

723-47-17200

CONTROL VALVE

|$19

BODY SUB ASS'Y

|$20

BODY SUB ASS'Y

|$21

BODY SUB ASS'Y

|$22

BODY SUB ASS'Y

|$23

BODY SUB ASS'Y

1

BLOCK,VALVE

1

BLOCK,VALVE

2

SPOOL

3

SPOOL

4

SPOOL

5

SPOOL

5

SPOOL

6

SPOOL

7

723-46-15130

PLUG

8

723-46-15140

PLUG

9

07002-50823

O-RING

10

708-7T-16460

BALL

11

723-46-15120

RETAINER

12

723-46-15260

RETAINER

13

723-46-14110

SPRING

14

723-46-14170

SPRING

15

723-46-14131

SPRING

16

723-46-15111

CASE

16

723-46-15110

CASE

17

700-93-11660

O-RING

18

01252-60820

BOLT

19

723-46-15410

CASE

20

723-46-15420

RETAINER

21

723-46-15450

PLUG

22

07002-53034

O-RING

23

723-46-15440

SPRING

24

723-46-15430

PISTON

25

PLUG

25

PLUG

26

723-46-15150

VALVE

27

723-46-14150

SPRING
