Запчасти Komatsu PC400-6C BM ЦИЛИНДР(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

208-63-X9060

CYLINDER GROUP,L.H.

G-1

208-63-X8300

CYLINDER GROUP,L.H.

G-1

208-63-X9070

CYLINDER GROUP,R.H.

G-1

208-63-X8310

CYLINDER GROUP,R.H.

|$6

208-63-08300

BOOM CYLINDER ASS'Y

1

208-63-53541

CYLINDER

2

707-76-10270

BUSHING

3

07145-10100

SEAL,DUST (KIT)

4

07020-00675

FITTING,GREASE

5

07043-00108

PLUG

6

208-63-59920

ROD

7

707-76-11130

BUSHING

8

07145-10110

SEAL,DUST (KIT)

9

707-71-32810

COLLAR

10

707-35-91640

RING,BACK-UP (KIT)

11

07000-55150

O-RING (KIT)

12

707-71-61111

PLUNGER

13

707-27-16920

HEAD

14

198-63-94170

SEAL,DUST (KIT)

15

07179-13126

RING,SNAP

16

707-52-90850

BUSHING

17

707-51-11730

PACKING,ROD (KIT)

18

707-51-11630

RING,BUFFER (KIT)

19

707-35-91640

RING,BACK-UP (KIT)

20

07000-55150

O-RING (KIT)

21

01010-82085

BOLT

22

707-88-75310

WASHER

23

707-36-16380

PISTON

24

01310-01216

SCREW

25

707-44-16180

RING,PISTON (KIT)

26

707-39-16820

RING,WEAR (KIT)

27

707-44-16910

RING

28

07001-05100

RING,BACK-UP (KIT)

29

07000-55100

O-RING (KIT)

30

208-63-53571

TUBE,L.H.

30

208-63-53671

TUBE,R.H.

31

208-63-53181

TUBE,L.H.

31

208-63-53281

TUBE,R.H.

32

01435-01055

BOLT

33

07000-53035

O-RING (KIT)

34

707-88-87110

BRACKET,L.H.

34

707-88-87120

BRACKET,R.H.

35

707-88-95770

BAND

36

01010-81240

BOLT

37

01643-51232

WASHER

38

07283-23442

CLIP

39

01643-31032

WASHER

40

01599-01011

NUT

41

01010-81025

BOLT

42

01643-31032

WASHER

43

07000-53032

O-RING

44

07378-11000

HEAD

45

07371-31049

FLANGE,SPLIT

46

07372-21035

BOLT

47

01643-51032

WASHER

|$58

707-99-67305

SERVICE KIT
