Запчасти Komatsu PC400-6 БЛОК КОНДИЦИОНЕРА (DEN-CON)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

Схема запчастей Komatsu PC400-6 - БЛОК КОНДИЦИОНЕРА (DEN-CON)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
1
2
3
4
5
5A
6
6A
6B
7
7A
8
9
10
10
11
12
13
14
14
15
16
17
18
19
20
21
21
22
23
24
25
26
27
27A
27B
27C
28
29
30
31
31
32
33
34
35
35
36
37
38
39
39
40
41
42
43
44
44
44
44
44
44
44
44
44
44
44
45
45
45
46
46
47
47
48
49
49
49
49

Артикул

Название

Примечание

Количество

|$0

203-979-6813

UNIT ASS'Y

|$1

203-979-6812

UNIT ASS'Y

1

TW534135-1200

CASE

2

TW534135-1300

CASE

3

TW534135-1020

CASE ASS'Y

4

TW534135-1120

CASE ASS'Y

5

TW534160-2020

SCROLL ASS'Y

5A

TW534160-2121

SCROLL ASS'Y

6

TW503700-2532

EVAPORATOR ASS'Y

6

TW503700-2531

EVAPORATOR ASS'Y

6A

TW582531-0200

SWITCH,PRESSURE

6B

TW503714-0830

EXPANSION VALVE,PRESSURE

7

TW502700-1721

HEATER CORE ASS'Y

7A

TW521430-0020

STEM ASS'Y

8

203-979-6840

FILTER

9

203-979-6850

FILTER

10

TW535011-0920

COVER

11

203-979-6860

RESISTOR

12

TW582550-9600

THERMOSTAT

13

TW502752-2380

MOTOR ACTUATOR

14

TW502752-2320

MOTOR ACTUATOR

15

TW534270-2920

DOOR

16

TW534270-3020

DOOR

17

TW534270-3120

DOOR

18

TW534270-3221

DOOR

19

TW534470-3400

LEVER

20

TW534470-3500

LEVER

21

TW534470-2200

LEVER

22

TW534470-3621

LEVER

23

TW534480-1400

ROD

24

TW534480-1600

ROD

25

TW534480-1700

ROD

26

TW534480-1500

ROD

27

TW503716-1900

FAN MOTOR ASS'Y

27A

TW523220-1800

FAN

27B

TW029600-8040

RING, SNAP

27C

TW592050-0500

RING, SNAP

28

TW534510-4600

AIR HOSE

29

TW592405-1600

ISOLATOR

30

TW592039-5900

WASHER

31

TW592055-0900

CLIP

32

TW592417-0300

CLIP

33

TW580530-6800

CLIP

34

TW580530-6901

CLIP

35

TW580521-6800

CLIP

36

TW580520-1300

CLIP

37

TW592024-3100

CLIP

38

TW582592-4722

RELAY ASS'Y

39

TW534103-0201

BRACKET

40

TW534103-0301

BRACKET

41

TW534186-4600

LINING

42

TW534186-4500

LINING

43

TW012554-0840

SCREW

44

TW012515-1640

TAPPING SCREW

45

TW012514-1640

TAPPING SCREW

46

TW580140-0300

TAPPING SCREW

47

TW580150-5200

TAPPING SCREW

48

TW536019-4422

WIRE HARNESS

49

TW592022-3600

TAPPING SCREW

Выбрано товаров: 59
