Запчасти Komatsu PC400-6 ОСНОВН. НАСОС (7/)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$1

708-2H-00191

PUMP ASS'Y

|$3

708-2H-01121

PUMP SUB ASS'Y

|$4

708-2H-04160

CRADLE ASS'Y

1

CRADLE

2

CAM,ROCKER

3

04020-01434

PIN

4

07000-B1009

O-RING

5

706-75-40340

BOLT

6

708-2H-24311

PISTON

7

708-2H-24220

ROD

8

04020-00514

PIN

9

708-2H-25870

CAM

10

01010-80825

BOLT

11

01643-30823

WASHER

12

708-2H-24260

STOPPER

13

07000-B3032

O-RING

14

07001-03032

RING

15

708-2H-24320

SCREW

16

01643-32460

WASHER

17

01583-52414

NUT

18

708-2H-24270

SCREW

19

708-1W-28910

O-RING

20

708-2H-24140

SPRING

21

708-2H-24130

PLUG

22

708-2L-24620

O-RING

23

708-2H-22140

COUPLING

24

708-2H-12420

RING

25

708-2H-21860

BEARING

26

708-2H-21820

GEAR

27

708-2H-21850

BUSHING

28

708-2H-21810

IMPELLER

29

04020-00820

PIN

30

708-2H-21830

GEAR,BEVEL

31

01010-61440

BOLT

32

01643-31445

WASHER

33

708-2H-21630

COVER

34

07000-A2105

O-RING

35

708-2H-05010

SHIM KIT

35

SHIM, 0.1MM

35

SHIM, 0.2MM

35

SHIM, 0.5MM

36

01010-81235

BOLT

37

01643-31232

WASHER
