Запчасти Komatsu PC400-3 РАДИАТОР И МАСЛООХЛАДИТЕЛЬ(№-8) КОМПОНЕНТЫ ДВИГАТЕЛЯ И ЭЛЕКТРИКА

|$0

208-03-00031

RADIATOR ASS'Y

|$1

208-03-00030

RADIATOR ASS'Y

1

208-03-31111

RADIATOR CORE ASS'Y

1

208-03-31110

RADIATOR CORE ASS'Y

2

101-03-13141

CAP

3

207-03-31170

FRAME

3A

207-03-31290

SHEET

3B

207-03-31280

SHEET

4

207-03-31180

SEAT

5

281-03-11150

CLAMP

6

281-03-11160

SEAT

7

01010-51020

BOLT

8

01643-51032

WASHER

9

281-03-11170

SHIM, 0.6MM

10

208-03-31120

OIL COOLER ASS'Y

11

01010-51635

BOLT

12

01643-31645

WASHER

13

207-03-31230

SHROUD

14

207-03-31240

SHROUD

15

01010-51060

BOLT

16

01643-31032

WASHER

17

207-03-31251

NET

17

207-03-31250

NET

18

01010-51025

BOLT

19

01643-31032

WASHER

20

207-03-12160

PIPE

20A

08034-00536

BAND

21

232-03-11210

CLIP

22

01010-51016

BOLT

23

01643-31032

WASHER

24

07283-24949

CLIP

25

01599-01011

NUT

26

01643-31032

WASHER

27

01010-51640

BOLT

28

01643-31645

WASHER

29

207-03-31191

STAY

30

01010-51630

BOLT

31

01643-31645

WASHER
