Запчасти Komatsu PC40-7 ГИДРОМОЛОТ РУКОЯТЬ (ГИДРОМОЛОТ)(№-) РАБОЧЕЕ ОБОРУДОВАНИЕ

Схема запчастей Komatsu PC40-7 - ГИДРОМОЛОТ РУКОЯТЬ (ГИДРОМОЛОТ)(№-) РАБОЧЕЕ ОБОРУДОВАНИЕ
1
2
3
4
5
6
7
8
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
39
40
41
41
42
43
44
45
45
46
46

Артикул

Название

Примечание

Количество

|1

20T-970-0040

BREAKER ASS'Y

|1

20T-970-7210

BREAKER

1

BK13011010

CYLINDER

2

BK13011020

PISTON

3

BK13011030

SLEEVE

4

BKE1022065

O-RING (K9)

5

BKE3110048

U-PACKING (K9)

6

BKE3120053

U-PACKING (K9)

7

BKE1022070

O-RING (K9)

8

BKE1012020

O-RING (K9)

9

BK100106038

PLUG

10

BK21310160

VALVE

11

BK13013040

SLEEVE

12

BK13013055

PLUG

13

BKE1022040

O-RING (K9)

14

BKE2122040

RING,BACK-UP (K9)

15

BK13013020

LINER,LINER

16

BKE1022040

O-RING (K9)

17

BKE2122040

RING,BACK-UP (K9)

18

BK13013021

PLUG,LINER

19

BKE1012020

O-RING (K9)

20

BKA030A3699

BOLT

21

BKC810A016

WASHER

|22

BK13032000

CAP ASS'Y,(BACK)

22

BK13032010

CAP,BACK

23

BKE1022085

O-RING (K9)

24

BK13012110

BODY,VALVE

25

BKR911101

VALVE (K9)

26

BK13012120

CAP

27

BKE1022025

O-RING (K9)

|28

BK13044000

CAP ASS'Y,(FRONT)

28

BK13044010

CAP,FRONT

29

BK13014110

BUSHING

30

BK13044210

BUSHING

31

BK21310450

FITTING,GREASE

32

BKD0510A17

PIN

33

BK21300189

PLUG

34

BK13014140

SLEEVE

35

BK13044310

PIN

36

BK13014320

PIN

|37

BK13012500

ROD ASS'Y,(SIDE)

37

BK13012510

ROD,SIDE

38

BK13012530

NUT

39

BKK10610

PLUG

40

BKK10618

PLUG

41

BKE10120125

O-RING

42

BKE1012020

O-RING

43

BKK10103A

PLUG

44

BKK10112A

PLUG

45

20T-70-25740

BUSHING

46

20T-70-71880

BUSHING

Выбрано товаров: 51
