Запчасти Komatsu PC40-2 5-СЕКЦИОНН. УПРАВЛЯЮЩ. КЛАПАН (/) (ДЛЯ SERVICE) ОПЦИОННЫЕ КОМПОНЕНТЫ

|$0

700-25-24000

VALVE ASS'Y

1

700-22-11110

BODY,VALVE

2

700-22-11130

BLOCK,VALVE

3

700-22-11150

COVER,VALVE

4

700-23-13120

SPOOL,TRAVEL, L.H.

5

700-22-11710

SPOOL,ARM, ATTACHMENT

6

700-24-13120

SPOOL,SWING

7

700-24-13130

SPOOL,SWING

8

07000-13040

O-RING

9

700-22-11450

O-RING

10

700-22-11252

U-PACKING

11

700-22-11430

COLLAR

12

700-22-11261

SEAL,DUST

13

700-22-11270

PLATE

14

700-22-11420

GASKET

15

01252-30616

BOLT

16

700-22-11281

PLATE

17

700-22-11290

RETAINER

18

700-22-11311

SPRING

19

700-23-13130

SPRING

20

700-22-11320

PLUG

21

700-22-11331

COVER

22

700-22-11351

PLUG

23

700-22-12340

BALL

24

700-22-12350

SPRING

25

07002-12434

O-RING

26

700-26-11150

PLUG

27

700-22-11360

PLUG

28

07000-12014

O-RING

29

07002-02434

O-RING

30

700-20-72000

VALVE ASS'Y

31

700-20-81000

VALVE ASS'Y

32

700-20-65000

VALVE ASS'Y

33

700-20-63001

VALVE ASS'Y

34

700-20-71000

VALVE ASS'Y

35

700-25-51000

VALVE ASS'Y

36

700-25-11220

BOLT

37

700-26-11170

ANGLE

38

700-25-11210

STUD

39

01580-10806

NUT
