Запчасти Komatsu PC390LL-10 A50601 AST- СТАРТЕР, KW ДВИГАТЕЛЬ

|$0

600-863-8112

STARTING MOTOR ASSEMBLY, 11 KW

1

KD1-09279-0090

NUT

2

KD1-0335-08002

WASHER, SPRING

3

KD1-0330-08022

WASHER

4

KD1-0345-08001

WASHER, SEAL

5

KD0-23303-0020

PIN

6

KD1-23914-0020

RING

7

KD1-23181-0020

STOPPER

8

KD0-23120-0180

SHAFT ASSEMBLY

9

KD0-23310-1740

BRACKET ASSEMBLY

10

KD1-23500-0970

CLUTCH ASSEMBLY

11

KD1-23320-0290

LEVER ASSEMBLY

12

KD0-09201-0850

BEARING, BALL

13

KD0-23600-0410

BRACKET ASSEMBLY

14

KD0-23611-1101

BRACKET

15

KD0-0274-06202

BOLT

16

KD1-23951-0051

PACKING

17

KD1-0400-30100

PIN

18

KD0-23100-0430

ARMATURE ASSEMBLY

19

KD0-47100-4651

SWITCH ASSEMBLY

20

KD0-23200-0671

YOKE ASSEMBLY

21

KD0-09271-3620

NAME PLATE

22

KD1-09211-1120

O-RING

23

KD0-23740-0351

BRUSH ASSEMBLY

24

KD0-23750-0490

HOLDER ASSEMBLY

25

KD0-47761-2681

COVER

26

KD0-47761-2691

COVER

27

KD0-09011-3140

SCREW

28

KD1-09211-0081

O-RING

29

KD0-23710-0221

BRACKET

30

KD0-09001-4380

BOLT

31

KD1-47921-0790

WASHER

32

KD0-0276-08402

BOLT

33

KD0-09057-0110

WASHER

34

KD1-23941-0040

WASHER, INSULATE

35

KD1-23921-0140

WASHER

36

KD1-23921-0130

WASHER

37

KD0-0055-05082

SCREW

38

KD0-09057-0190

WASHER

39

KD0-0020-05062

SCREW

40

KD1-0345-05001

WASHER, SEAL

41

KD1-0240-06305

BOLT

42

KD0-25000-8521

SWITCH ASSEMBLY

43

KD0-0270-06602

BOLT

44

KD0-47927-1390

HOLDER

45

KD0-47761-2671

COVER

46

KD1-09211-0981

O-RING

47

KD0-09006-0660

NUT

48

KD0-09006-0670

NUT

49

KD1-09257-0050

BAND

50

KD0-09275-1430

PLATE, CAUTION
