Запчасти Komatsu PC390LL-10 A50601 AEE- ГЕНЕРАТОР, AMP ДВИГАТЕЛЬ

Схема запчастей Komatsu PC390LL-10 A50601 - AEE- ГЕНЕРАТОР, AMP ДВИГАТЕЛЬ
17
16
15
13
14
2
6
9
11
9
7
10
9
9
8
5
12
6
20
28
25
29
9
3
30
26
1
21
27
18
4
9
24
23
3
22
19
31

Артикул

Название

Примечание

Количество

|$0

600-861-6110

ALTERNATOR, 60 AMP

1

KD0-35100-0300

ROTOR ASSEMBLY

2

KD1-33923-0790

COLLAR

3

KD1-35923-0160

COLLAR

4

KD0-09201-0980

BEARING, BALL

5

KD0-35200-0460

STATOR ASSEMBLY

6

KD0-35300-0350

BRACKET ASSEMBLY

7

KD0-09201-1140

BEARING, BALL

8

KD0-35926-0070

RETAINER

9

KD0-35951-0060

PACKING

10

KD0-35926-0090

RETAINER

11

KD1-33926-0730

RETAINER

12

KD0-0275-06802

BOLT

13

KD0-35411-0640

PULLEY

14

KD0-35421-0240

FAN

15

KD1-0330-16012

WASHER

16

KD1-0335-16002

WASHER, SPRING

17

KD0-0280-16022

NUT

18

KD0-35120-0290

COIL, FIELD

|$19

KD0-35700-0950

BRACKET ASSEMBLY

19

KD0-35710-1150

BRACKET

20

KD0-35730-0700

RECTIFIER ASSEMBLY

21

KD0-09170-2501

CONDENSER

22

KD0-35943-0150

BUSHING, INSULATE

23

KD0-35923-0130

COLLAR

24

KD0-35943-0160

BUSHING, INSULATE

25

KD0-35943-0140

BUSHING, INSULATE

26

KD0-35943-0170

BUSHING, INSULATE

27

KD0-35784-0210

BAR, CONNECT

28

KD0-35784-0290

BAR, PLATE

29

KD0-09057-0220

WASHER

30

KD7-35719-0211

REGULATOR ASSEMBLY

31

KD0-35761-0250

COVER

Выбрано товаров: 33
