Запчасти Komatsu PC390LL-10 A50601 N-A МОТОР ПОВОРОТА ВАЛ ПОВОРОТН. КРУГ И КОМПОНЕНТЫ

1

706-7K-41610

SHAFT

2

706-77-43890

BEARING

3

706-7K-41810

SPACER

4

706-77-42051

SPRING

5

706-77-42041

SEAT

6

706-77-42890

BEARING

7

706-77-05010

SPACER KIT

|$9

NSS

SPACER, T = 2.3 MM

|$10

NSS

SPACER, T = 2.5 MM

|$11

NSS

SPACER, T = 2.7 MM

8

04064-06525

RING, SNAP, FOR SHAFT SIDE

9

706-8J-41420

SEAL, OIL

10

706-7K-41920

SPACER

11

04065-07525

RING, SNAP, FOR HOLE SIDE

12

706-7K-41210

CYLINDER BLOCK

13

706-7K-41710

PLATE

14

708-18-13230

PIN

15

706-7K-41120

SHAFT

16

706-77-42130

RING

17

706-7K-41140

SPRING

|$22

706-7K-05010

RETAINER KIT

18

NSS

RETAINER

19

NSS

SCREW

20

706-7K-41160

PISTON SUBASSEMBLY

21

706-7K-91340

PLATE

22

706-7K-91350

DISC

23

706-7K-91111

BRAKE PISTON

24

07000-B5230

O-RING

25

706-86-90290

O-RING

26

706-7K-91360

SPRING
