Запчасти Komatsu PC390LL-10 A50601 K-A КАБИНА ЗАДН. КРЫШКА OPERATORS ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

1

20Y-53-12371

COVER

2

208-53-12290

HOOK

3

01580-10403

NUT

4

01640-20408

WASHER

5

01601-20410

WASHER

|$5

2A5-53-11731

COVER ASSEMBLY, FUSES

6

22U-43-22340

PULLER

7

2A5-53-11651

COVER, FUSE

8

08041-00500

FUSE, 5 AMP.

9

08041-01000

FUSE, 10 AMP

10

08041-02000

FUSE, 20 AMP

11

08041-02500

FUSE, 25 AMP

12

08041-03000

FUSE, 30 AMP

13

01435-80616

BOLT

14

20Y-53-12310

COLLAR

15

208-979-7560

GRILLE

16

2A5-53-11680

COVER

17

09452-14503

CATCHER

18

01370-10308

SCREW

19

2A5-53-11690

COVER

20

208-53-12410

PLATE

21

01370-20308

SCREW

22

208-53-12320

PIN

23

208-53-12330

RING

24

01435-80616

BOLT

25

20Y-53-12310

COLLAR

26

2A5-53-12341

COVER

27

01010-D0620

BOLT

28

01643-70623

WASHER

29

20Y-53-12310

COLLAR

30

23D-950-4450

BUTTON

31

20Y-53-12860

SPACER

32

2A5-06-11881

CONVERTER

33

01252-80520

BOLT, HEXAGON SOCKET HEAD

34

01640-50508

WASHER

35

2A5-06-12181

SOCKET, 12 V POWER SOURCE

36

2A5-06-12172

WIRING HARNESS

37

08034-20519

STRAP, TIE

38

01010-81240

BOLT

39

01643-31232

BOLT
