Запчасти Komatsu PC390LL-10 A50601 H-A ОСНОВН. НАСОС COMPLETE ПОРШЕНЬ НАСОС ASSEMBLY (/) ГИДРАВЛИКА

1

708-2G-12180

SHAFT

2

708-2G-12251

BEARING

3

708-2G-05010

WASHER KIT

|$4

NSS

WASHER, T=3.0 MM

|$5

NSS

WASHER, T=3.1 MM

|$6

NSS

WASHER, T=3.2 MM

4

708-1F-12270

RING, SNAP

5

708-2G-12230

SEAL, OIL

6

708-8H-32160

SPACER

7

04065-07825

RING, SNAP

|$11

708-2G-04262

CYLINDER BLOCK ASSEMBLY

8

NSS

CYLINDER BLOCK

9

NSS

PLATE, VALVE

10

708-18-13230

PIN

11

04065-05520

RING, SNAP (HOLE SIDE)

12

708-2G-13131

SEAT

13

708-2G-13152

SPRING

14

708-2G-13141

SEAT

15

708-2G-13510

GUIDE, RETAINER

16

708-2H-23360

PIN

17

708-2G-13341

RETAINER, SHOE

18

708-2G-13370

PISTON SUBASSEMBLY

|$23

708-2G-04670

CRADLE SUBASSEMBLY

19

NSS

CRADLE

20

NSS

CAM, ROCKER

21

04020-01434

PIN, DOWEL

22

07000-B1009

O-RING

23

01252-61230

BOLT
