Запчасти Komatsu PC390LC-10 T-B ЦИЛИНДР КОВША ДЛЯ . M И . M РУКОЯТЬ РАБОЧЕЕ ОБОРУДОВАНИЕ

|$0

707-F1-01280

BUCKET CYLINDER

1

707-13-15570

CYLINDER

2

707-58-11850

ROD, PISTON

3

707-76-90490

BUSHING

4

07145-00090

SEAL, DUST

5

07020-00000

FITTING, GREASE

6

207-63-76170

BUSHING

7

207-70-72120

SEAL, DUST

8

07020-00000

FITTING, GREASE

9

207-27-15620

HEAD, CYLINDER

10

707-56-11740

SEAL, DUST

11

07179-13126

RING, SNAP

12

707-52-90851

BUSHING

13

707-51-11860

PACKING, ROD

14

707-51-11650

RING, BUFFER

15

707-35-31410

RING, BACK-UP

16

07000-B5140

O-RING

17

707-88-81530

BOLT

18

707-75-11040

RING, SNAP

19

707-36-15260

PISTON

20

707-44-15150

RING, PISTON

21

707-39-15110

RING, WEAR

22

707-35-31000

RING, BACK-UP

23

07000-B5100

O-RING

24

707-44-15911

RING, BACK-UP

25

01310-01216

SCREW

26

707-86-16120

TUBE

27

707-86-00850

TUBE

28

07372-21060

BOLT

29

01643-51032

WASHER

30

07000-13035

O-RING

31

707-88-51410

BRACKET

32

07372-21240

BOLT

33

01643-51232

WASHER

34

707-88-10150

CLAMP

35

01010-81245

BOLT

36

01643-31232

WASHER

37

07371-31049

FLANGE, SPLIT

38

707-88-33040

CAP

39

07372-21035

BOLT

40

01643-51032

WASHER

|$41

707-99-59550

K06 SERVICE KIT
