Запчасти Komatsu PC390LC-10 K-A КАБИНА ПЕРЕДН. ОКНА - ВЕРХН. OPERATORS ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

|$1

2A5-53-00051

WINDOW ASSEMBLY

1

NSS

FRAME

2

20Y-53-11520

GLASS

3

20Y-54-51531

SEAL

4

20Y-53-11551

SEAL

5

22B-54-15411

LOCK ASSEMBLY

6

22B-54-15440

CASE

7

22B-54-15470

KNOB

8

22B-54-15421

LOCK ASSEMBLY

9

22B-54-15450

CASE

10

22B-54-15480

KNOB

11

01435-40812

BOLT

12

20Y-54-52621

ROLLER

13

20Y-54-52681

ROLLER

14

20Y-53-12330

PIN

15

205-54-14590

HANDLE

16

01245-00616

SCREW, HEXAGON SOCKET HEAD

17

01643-70623

WASHER

18

20Y-53-12830

BRACKET

19

01245-00816

SCREW, HEXAGON SOCKET HEAD

20

01643-70823

WASHER, FLAT

21

2A5-53-12510

STOPPER

22

20Y-54-51680

STOPPER

23

01252-80616

BOLT, HEXAGON SOCKET HEAD

24

01643-70623

WASHER

25

20Y-53-11561

BLOCK ASSEMBLY

26

01245-00816

SCREW, HEXAGON SOCKET HEAD

27

01643-70823

WASHER, FLAT

28

20Y-53-11661

BRACKET

29

01245-00816

SCREW, HEXAGON SOCKET HEAD

30

01643-70823

WASHER, FLAT

31

21J-06-12440

SWITCH

32

01583-01811

NUT

33

20Y-53-11581

BRACKET

34

01435-00612

BOLT

35

2A5-53-12850

BRACKET

36

01435-00612

BOLT

37

08059-00515

CLIP

38

20Y-54-11611

STOPPER

39

01580-11008

NUT, FLANGED

40

20Y-54-51621

STRIKER

41

01584-31008

NUT

42

01643-71032

WASHER

43

20Y-53-11540

SEAL

44

20Y-54-51420

SEAL

45

2A5-53-11481

COVER

46

22B-54-16461

RIVET
