Запчасти Komatsu PC390LC-10 H-A ОСНОВН. УПРАВЛЯЮЩ. КЛАПАН COMPLETE ASSEMBLY (/) ГИДРАВЛИКА

|$1

723-48-26800

CONTROL VALVE

|$2

723-40-73200

VALVE ASSEMBLY

1

NSS

VALVE BODY

2

NSS

SPOOL

3

NSS

PLUG

4

723-40-72800

PLATE ASSEMBLY

5

702-21-61600

VALVE, PILOT

6

700-80-61260

O-RING

7

723-11-19960

O-RING

8

702-21-54180

Screw

9

702-16-55610

O-RING

10

723-46-15111

CASE

11

07430-71380

O-RING

12

723-40-71330

RETAINER

13

723-40-71340

SPRING

14

723-40-71350

RETAINER

15

01252-60816

BOLT

16

723-40-71870

UNION

17

02896-11008

O-RING

18

07002-11423

O-RING

19

07040-11409

PLUG

20

07002-11423

O-RING

21

01252-60855

BOLT, HEXAGON SOCKET HEAD

22

01252-60635

BOLT, HEXAGON SOCKET HEAD

23

NSS

SPOOL ASSEMBLY

24

723-40-71850

SPRING

25

723-46-18720

O-RING

26

NSS

SPOOL

27

723-40-71390

SPRING

28

723-46-18720

O-RING

|$31

723-40-71900

VALVE ASSEMBLY

29

723-40-91600

VALVE ASSEMBLY, RELIEF

30

702-16-53920

O-RING

31

07002-11623

O-RING

32

NSS

BLOCK

33

NSS

SPOOL

34

NSS

SPRING

35

702-21-55620

PLUG

36

07002-11423

O-RING

37

702-21-55710

SEAT

38

702-21-55720

SPRING

39

04260-00793

BALL

40

07000-11009

O-RING

41

NSS

PLUG
