Запчасти Komatsu PC38UU-3 MULTI PATERN (ДЛЯ WAY) (КЛАПАН) ГИДРАВЛИКА

|1

22F-62-13321

VALVE ASS'Y

1

22F-62-13460

BODY

2

22F-62-13450

SHAFT

3

22F-62-13431

LEVER

4

22F-62-13310

BRACKET

5

07000-03025

O-RING

6

07000-03032

O-RING

7

07003-12733

GASKET

8

07043-00108

PLUG

9

04260-00793

BALL

10

700-84-11750

SPRING

11

22F-62-13250

PLUG

12

01010-80616

BOLT

13

01643-30623

WASHER

14

21X-62-32350

HOSE¤ 500MM

|14

20T-62-84280

HOSE¤ 500MM

15

20C-62-34710

HOSE¤ 240MM

|15

21X-62-22270

HOSE¤ 250MM

16

20C-62-34560

HOSE¤ 410MM

|16

20T-62-84290

HOSE¤ 400MM

17

22F-62-13181

HOSE¤ 430MM

|17

22F-62-13180

HOSE¤ 400MM

18

21U-62-38310

ELBOW

|18

201-62-75420

ELBOW

19

21U-62-24110

ELBOW

|19

07235-10210

ELBOW

20

21A-62-12350

NIPPLE

|20

07230-20210

UNION

21

07002-11423

O-RING

22

01010-81040

BOLT

23

01643-31032

WASHER

24

21X-62-33610

BRACKET

25

21X-62-33620

BRACKET

26

01010-81040

BOLT

27

01010-81020

BOLT

28

01643-31032

WASHER

29

08034-20519

BAND

30

07095-00526

CUSHION

31

07095-20522

CUSHION

|31

07095-20523

CUSHION

32

08210-01202

SPIRAL TUBE

33

21X-62-33631

CUSHION

|33

21X-62-33630

CUSHION
