Запчасти Komatsu PC38UU-3 MULTI PATERN (ДЛЯ WAY) (КЛАПАН)(№8-) ГИДРАВЛИКА

|1

21U-62-34505

VALVE ASS'Y

1

21U-62-34573

LEVER

2

21U-62-34520

PLATE

3

21U-62-34590

PLATE

4

01252-70620

BOLT

5

01643-30623

WASHER

6

21U-62-34690

COVER

7

01252-60620

BOLT

8

07016-00306

SEAL

9

BODY

10

07000-03028

O-RING

11

07000-02060

O-RING

12

22F-62-13250

PLUG

13

04260-00793

BALL

14

700-84-11750

SPRING

15

SHAFT

|15

02720-40104

PLUG

16

203-62-58980

COVER

17

01252-60616

BOLT

18

01252-70612

BOLT

19

01643-30623

WASHER

20

21U-62-34581

BOLT

21

01640-20816

WASHER

22

04050-12015

PIN

23

21U-62-38310

ELBOW

24

21U-62-24110

ELBOW

25

21U-62-24160

ELBOW

26

07002-11423

O-RING

27

20C-62-34690

HOSE¤ 120MM

28

21U-62-38320

HOSE¤ 300MM

29

21X-62-32330

HOSE¤ 200MM

30

20C-62-34720

HOSE¤ 150MM

31

21X-62-32340

HOSE¤ 300MM

32

20C-62-34750

HOSE¤ 150MM

33

08210-01215

SPIRAL TUBE
